MCU:
STM32F405RET6 Input Power:
3S-6S Dimensions:
38.5*38.5mm（30.5x30.5mm hole diameter 4mm） IMU:
ICM-42688 OSD:
AT7456E Barometer:
SPL06-001 Black box:
Support（capacity：16M） BEC:
5V/2A、9V/2A DJI VTX:
Using a 6-pin connector IIC:
Support UART:
UART1，UART2，UART3，UART6，UART5 for ESC Telemetry USB Port:
TYPE-C Galvanometer port:
Pad CUR ESC outputs:
M1-M8 LED:
Support external LED BetaFlight Camera tuning pad:
Pad CC Target firmware:
Betaflight_4.3.2_STM32F405 Receiving machine:
Support SBUS，IBUS，DSM2/X，TBS，CRSF Buzzer:
Yes RSSI:
Yes Weigh:
7.23g
